Description
Dura-Tech drafting stations are constructed from 16 and 18 gauge all welded base components with a 1″ thick laminate drafting area and 1″ laminate reference area. All tops are edged in 3MM PVC edging. These stations feature a rear modesty panel and an integrated wire tray for easy wire management. Units are available with a 10-position adjustable tilt work area and a 30″W fixed flat reference area. Stations come standard in a 28″ height. Height dimension listed is to bottom of work surface, for overall working height add 1″ for thickness of top. Storage cabinets are available in three configurations (contact us for other options).
Model # / Dimensions / Cabinet Option
DTF-3030.A-J / 30″D x 60″W x 28″H / Single Door Cabinet
DTF-3036.A-J / 30″D x 66″W x 28″H / Single Door Cabinet
DTF-3042.A-J / 30″D x 72″W x 28″H / Single Door Cabinet
DTF-3030.A-D / 30″D x 60″W x 28″H / 4 Drawer Cabinet
DTF-3036.A-D / 30″D x 66″W x 28″H / 4 Drawer Cabinet
DTF-3042.A-D / 30″D x 72″W x 28″H / 4 Drawer Cabinet
DTF-3030.A-C / 30″D x 60″W x 28″H / 6 Drawer Cabinet
DTF-3036.A-C / 30″D x 66″W x 28″H / 6 Drawer Cabinet
DTF-3042.A-C / 30″D x 72″W x 28″H / 6 Drawer Cabinet
*Images shown include optional accessories & computers that are not included.
